UGreen HDMI Video Capture Device

This video capture device includes separate 3.5mm ports for audio output (3-pole/4-pole headphones) and input (2-pole microphone), providing versatility for voiceovers, commentary, and sound effects during your streams. A 48KHz/24-bit sampling rate ensures crystal-clear audio quality with minimal distortion, making it an ideal choice for professional-grade streaming. The UGreen HDMI Video Capture Device is compatible with popular software such as OBS Studio, XSplit, Potplayer, and QuickTime Player, and works across various operating systems including Windows, macOS, Linux, and Android, ensuring a versatile and user-friendly experience.

Key Features:

• 4K Input and 1080P Output: Supports HDMI input up to 4K@30Hz with a loop-out fixed at 1080P@60Hz, providing clear and smooth visuals for your live streams and recordings.
• High-Speed USB 3.0 Type-C Connection: Equipped with a USB 3.0 Type-C port for capture, delivering up to 5Gbps transfer rates, ensuring reliable 1080P@60Hz capture performance.
• Versatile Audio Options: Features separate 3.5mm ports for audio output (compatible with 3-pole/4-pole headphones) and audio input (2-pole microphone), allowing for real-time commentary and sound mixing.
• Superior Audio Quality: Offers a sampling rate of 48KHz/24-bit, SNR ≥90dB, and THD < -80dB, delivering high-fidelity audio with low noise and distortion for a professional streaming experience.
• Wide Compatibility: Works with popular streaming software such as OBS Studio, XSplit, Potplayer, and QuickTime Player, and supports multiple operating systems including Windows, macOS 10.5+, Linux kernel 2.4.6+, and Android.

Specifications:

• • Input Port: HDMI IN (supports up to 4K@30Hz)
  • Loop Out Port: HDMI OUT (fixed at 1080P@60Hz)
  • Capture Port: USB-C (supports 1080P@60Hz)
  • USB-C Port: USB 3.0, with up to 5Gbps transfer rate
  • Audio Output: 3.5mm 3-pole/4-pole headphones
  • Audio Input: 3.5mm 2-pole microphone
  • Audio Sampling Rate: 48KHz/24-bit
  • Signal-to-Noise Ratio (SNR): ≥90dB
  • Total Harmonic Distortion (THD): < -80dB
  • Compatible Operating Systems: Windows, Android, macOS 10.5+, Linux kernel 2.4.6+
  • Compatible Software: OBS Studio, XSplit, Potplayer, QuickTime Player
